Wireless Portable Tabletop Water Polo Mini Scoreboard

The Wireless Portable Tabletop Mini Scoreboard is a versatile solution for water polo or any sport that requires displaying period/shot, game time, and home/guest scores.

Its rugged powder-coated aluminum enclosure is designed to withstand harsh conditions, with all digits and circuit boards coated to prevent corrosion. The high gain flush mount patch antenna is mounted internally and protected by a Lexan cover to prevent damage. Integrated 2.4GHz wireless technology offers customisable options without the risk of interference, enabling multiple games to operate in close range.

The scoreboard is compatible with the System 6 timing console and 2.4GHz wireless scoreboard adapter, or on-deck cabling.

Note: WTTC-2 has ntegrated the new FINA rules Amendment #1: WP20:

The time keeper recording the possession time shall reset the clock to 20 seconds when
a) the ball is put into play after awarding a corner throw
b) after a rebound after a shot which does not cause change of possession and
c) after an exclusion

Features:

• High visibility LED digits
• Lightweight and portable
• Includes handle for easy portability
• Available with or without batteries
• Indoor or outdoor use
• Viewing distance of at least 50m
• Displays data received from wireless controller
• Flexible mounting options

Options:

• External horn kit (as shown) PSPL69543
• 75mm Legs to suit Wireless Portable Mini Water Polo Scoreboard PSPL69541
• 900mm Legs to suit Wireless Portable Mini Water Polo Scoreboard PSPL69542
• Wallmount kit
• Wheeled scoreboard caddy

Dimensions:

34.9cm x 121.9cm x 10.2cm (H x W x D)
Weight: 13.2 kg
Digit size: 12.7cm (5″)
Power: 100-240V, 2A, 50/60Hz
IP53 Rating

Add Deck Clocks
Each Deck Clock features an integrated horn, which produces separate shot and game tones. The Deck Clock can be used as a pace / time of day clock when not being used for competition.
Game & shot time are displayed in a rugged polyethylene moulded plastic enclosure that is water & sun resistant & completely corrosion free.

• 25.4 cm (10”) Amber LED digits display shot time
• 12.7 cm (5”) LED Red digits display game time
• Integrated horn – performs separate shot and game tones
• Integrated back-up batteries – Low battery & charging indicator
• Use as a deck side pace/time of day clock when not being used for competition

Additional Deck Clocks can be added to systems at additional cost.

Sold as a pair.

Power: Battery or 120/240VAC, Auto-sensing
Operating distance: Up to 300 m
Dimension: 81.3 cm x 47 cm x 30.5 cm (H x W x D)
Weight: 13.6 kgs
Code: PSPL69520

Add a Controller

The system is designed for completely wireless operation. This scoreboard can be run with the System 6 and a 2.4GHz wireless scoreboard adapter (WA-2), wireless tabletop controller with water polo software (WTTC-2), or wired with on-deck cabling. The Tabletop Controller (WTTC-2) is required to adjust the LED intensity up or down, and is recommended for indoor users or users that switch between indoor and outdoor use.

Each controller features an operating distance up to 300 metre’s, buttons with tactile dome feedback, and large transflective LCD screens that are easily readable in all environments from darkness to bright sunlight.

Table Top Controller (WTTC-2)
Allows additional flexibility & control dots

• Large transflective LCD screen-easily readable in all environments from darkness to bright sunlight
• Buttons with tactile dome feedback
• Interchangeable keypad overlay
• 2.4 GHz Wireless Handheld
• Unit has 12 independent channels & 16 independent networks per channel that provide reliable communication for up to 192 separate games at a facility.
• Power: DC 5V, max 1.0 AMP from external A/C power supply or PC. No internal battery.

Can run from an external battery. USB compatible 3.7V 10000mAh 38Wh external battery with input/output of 5V/1.8A. (Not supplied)

Operating distance: Up to 300 m
Dimension: 307 mm x 231 mm x 104 mm (W x L x H)
Weight: 200 g
Code: PSPL69525

RSR Controller
RSR (Run/Stop/Reset Button) can be added.
Code: PSPL69535

All components sold separately.
